EPIC® Pin & Sleeve Connectors |
60 Amp: North American Version |
IP 66/67   |
 |
 |
Technical Data |
||
| Impact Resistance: | 20J | |
| Ambient Temperature: | -25°C to 70°C | |
| Flame Resistance: | ||
 Glow Wire Test: Enclosure: |
960°C | |
| Glow Wire Test: Contact Enclosure: |
960°C | |
| Self-Extinguishing: Enclosure: |
UL94-V0 | |
| Self-Extinguishing: Contact Carrier: |
UL94-V0 | |
 |
||
Part Numbers |
||
Part
Number |
Voltage |
#
of Wires |
#
of Poles |
Ground-Clock
Position |
408324FX |
125 |
3 |
1+N+PE |
4 |
408326FX |
250 |
3 |
2+PE |
6 |
 |
||||
408332FX |
125/250 |
4 |
2+N+PE |
12 |
408339FX |
3ø250 |
4 |
3+PE |
9 |
408337FX |
3ø480 |
4 |
3+PE |
7 |
|
||||
408349FX |
3øY
120/208 |
5 |
3+N+PE |
9 |
408347FX |
3øY
277/480 |
5 |
3+N+PE |
7 |
|
||||
| Mating Components: | ||
| CEE Straight
Male Plug with Cable Gland, IP 67 |
||
|
  |
|
||||||
|
||||||
