EPIC® Pin & Sleeve Connectors |
32 Amp: International Version |
 IP 44 |
 |
|
Technical Data |
||
| Impact Resistance: | 8J | |
| Ambient Temperature: | -25°C to 70°C | |
| Flame Resistance: | ||
 Glow Wire Test: Enclosure: |
850°C | |
| Glow Wire Test: Contact Enclosure: |
850°C | |
| Self-Extinguishing: Enclosure: |
UL94-V2 | |
| Self-Extinguishing: Contact Carrier: |
UL94-V2 | |
 |
||
Part Numbers |
||
Part
Number |
Voltage |
#
of Wires |
#
of Poles |
Ground-Clock
Position |
433211 |
110
- 130 |
3 |
2+PE |
4 |
443211 |
4 |
3+PE |
4 |
|
453211 |
5 |
3+N+PE |
4 |
|
 |
||||
433222 |
200
- 250 |
3 |
2+PE |
6 |
443222 |
4 |
3+PE |
9 |
|
453222 |
5 |
3+N+PE |
9 |
|
|
||||
433238 |
380
- 415 |
3 |
2+PE |
9 |
443238 |
4 |
3+PE |
6 |
|
453238 |
5 |
3+N+PE |
6 |
|
|
||||
433250 |
480
- 500 |
3 |
2+PE |
7 |
443250 |
4 |
3+PE |
7 |
|
453250 |
5 |
3+N+PE |
7 |
|
|
||||
443244 |
440
- 460 |
4 |
3+PE |
11 |
453244 |
5 |
3+N+PE |
|
|
|
||||
Mating Components: |
||
| MULTIMAX
Male Plug with Cable Sleeve, IP 44 |
||
| CEE Straight Male Plug with
Cable Gland, IP 44 |
||
|
|
|
 |
 |
||
