EPIC® Pin & Sleeve Connectors |
32 Amp: International Version |
 IP 67 |
 |
 |
Technical Data |
||
| Impact Resistance: | 8J | |
| Ambient Temperature: | -25°C to 70°C | |
| Flame Resistance: | ||
 Glow Wire Test: Enclosure: |
850°C | |
| Glow Wire Test: Contact Enclosure: |
850°C | |
| Self-Extinguishing: Enclosure: |
UL94-V2 | |
| Self-Extinguishing: Contact Carrier: |
UL94-V2 | |
 |
||
Part Numbers |
||
Part
Number |
Voltage |
#
of Wires |
#
of Poles |
Ground-Clock
Position |
473206 |
110
- 130 |
3 |
2+PE |
4 |
473216 |
4 |
3+PE |
4 |
|
473226 |
5 |
3+N+PE |
4 |
|
 |
||||
473306 |
200
- 250 |
3 |
2+PE |
6 |
473316 |
4 |
3+PE |
9 |
|
473326 |
5 |
3+N+PE |
9 |
|
|
||||
473406 |
380
- 415 |
3 |
2+PE |
9 |
473416 |
4 |
3+PE |
6 |
|
473426 |
5 |
3+N+PE |
6 |
|
|
||||
473506 |
480
- 500 |
3 |
2+PE |
7 |
473516 |
4 |
3+PE |
7 |
|
473526 |
5 |
3+N+PE |
7 |
|
|
||||
473466 |
440
- 460 |
4 |
3+PE |
11 |
473536 |
5 |
3+N+PE |
11 |
|
|
||||
Mating Components: |
||
| CEE Straight
Male Plug with Cable Gland, IP 67 |
||
| CEE
Angled 82° Male Inlet, IP 67 |
||
|
|
|
 |
 |
||
