EPIC® Pin & Sleeve Connectors |
32 Amp: International Version |
 IP 67 |
 |
  |
Technical Data |
||
| Impact Resistance: | 8J | |
| Ambient Temperature: | -25°C to 70°C | |
| Flame Resistance: | ||
 Glow Wire Test: Enclosure: |
850°C | |
| Glow Wire Test: Contact Enclosure: |
850°C | |
| Self-Extinguishing: Enclosure: |
UL94-V2 | |
| Self-Extinguishing: Contact Carrier: |
UL94-V2 | |
 |
||
Part Numbers |
||
Part
Number |
Voltage |
#
of Wires |
#
of Poles |
Ground-Clock
Position |
471267 |
110
- 130 |
3 |
2+PE |
4 |
471277 |
4 |
3+PE |
4 |
|
471287 |
5 |
3+N+PE |
4 |
|
 |
||||
471367 |
200
- 250 |
3 |
2+PE |
6 |
471377 |
4 |
3+PE |
9 |
|
471387 |
5 |
3+N+PE |
|
|
|
||||
471467 |
380
- 415 |
3 |
2+PE |
9 |
471477 |
4 |
3+PE |
6 |
|
471487 |
5 |
3+N+PE |
6 |
|
|
||||
471556 |
480
- 500 |
3 |
2+PE |
7 |
471577 |
4 |
3+PE |
7 |
|
471567 |
5 |
3+N+PE |
7 |
|
|
||||
471587 |
440
- 460 |
4 |
3+PE |
11 |
471597 |
5 |
3+N+PE |
|
|
|
||||
Mating Components: |
||
| CEE Straight
Male Plug with Cable Gland, IP 67 |
||
|
|
|
||||||
|
||||||
