EPIC® Pin & Sleeve Connectors |
|
20 Amp: North American Version |
IP 44   |
 |
|
 |
||
| Impact Resistance: | 8J | |
| Ambient Temperature: | -25°C to 70°C | |
| Flame Resistance: | ||
Glow Wire Test: Enclosure: |
850°C | |
|
Glow Wire Test: Contact Enclosure: |
850°C | |
|
Self-Extinguishing: Enclosure: |
UL94-V2 | |
|
Self-Extinguishing: Contact Carrier: |
UL94-V2 | |
 |
||
 |
||
|
Part
Number |
Voltage |
#
of Wires |
#
of Poles |
Ground-Clock
Position |
|
471262FX |
125 |
3 |
1+N+PE |
4 |
|
471362FX |
250 |
3 |
2+PE |
6 |
|
471552FX |
480 |
3 |
2+PE |
7 |
 |
||||
|
471862FX |
125/250 |
4 |
2+N+PE |
12 |
|
471372FX |
3ø250 |
4 |
3+PE |
9 |
|
471572FX |
3ø480 |
4 |
3+PE |
7 |
|
||||
|
471332FX |
3øY
120/208 |
5 |
3+N+PE |
9 |
|
471562FX |
3øY
277/480 |
5 |
3+N+PE |
7 |
|
||||
|
||||
 |
||
| MULTIMAX Male
Plug with Cable Sleeve, IP 44 |
||
|
CEE Straight Male Plug with
Cable Gland, IP 44 |
||
|
CEE 90° Male Plug with
Cable Gland, IP 44 |
||
  |
