EPIC® Pin & Sleeve Connectors |
|
20 Amp: North American Version |
IP 67   |
 |
 |
 |
||
| Impact Resistance: | 8J | |
| Ambient Temperature: | -25°C to 70°C | |
| Flame Resistance: | ||
Glow Wire Test: Enclosure: |
850°C | |
|
Glow Wire Test: Contact Enclosure: |
850°C | |
|
Self-Extinguishing: Enclosure: |
UL94-V2 | |
|
Self-Extinguishing: Contact Carrier: |
UL94-V2 | |
 |
||
 |
||
|
Part
Number |
Voltage |
#
of Wires |
#
of Poles |
Ground-Clock
Position |
|
476203FX |
125 |
3 |
1+N+PE |
4 |
|
476303FX |
250 |
3 |
2+PE |
6 |
|
476833FX |
125/250 |
4 |
2+N+PE |
12 |
|
476313FX |
3ø250 |
4 |
3+PE |
9 |
|
476513FX |
3ø480 |
4 |
3+PE |
7 |
|
476323FX |
3øY
120/208 |
5 |
3+N+PE |
9 |
|
476523FX |
3øY
277/480 |
5 |
3+N+PE |
7 |
 |
||||
|
||||
 |
||
|
CEE Straight Female Connector
with Cable Gland, IP 67 |
||
  |
