EPIC® Pin & Sleeve Connectors |
|
16 Amp: International Version |
IP 67  |
 |
 |
 |
||
| Impact Resistance: | 8J | |
| Ambient Temperature: | -25°C to 70°C | |
| Flame Resistance: | ||
Glow Wire Test: Enclosure: |
850°C | |
|
Glow Wire Test: Contact Enclosure: |
850°C | |
|
Self-Extinguishing: Enclosure: |
UL94-V2 | |
|
Self-Extinguishing: Contact Carrier: |
UL94-V2 | |
 |
||
 |
||
|
Part
Number |
Voltage |
#
of Wires |
#
of Poles |
Ground-Clock
Position |
|
473203 |
110
- 130 |
3 |
2+PE |
4 |
|
473213 |
4 |
3+PE |
4 |
|
|
473223 |
5 |
3+N+PE |
4 |
|
 |
||||
|
473303 |
200
- 250 |
3 |
2+PE |
6 |
|
473313 |
4 |
3+PE |
9 |
|
|
473323 |
5 |
3+N+PE |
9 |
|
|
|
||||
|
473403 |
380
- 415 |
3 |
2+PE |
9 |
|
473413 |
4 |
3+PE |
6 |
|
|
473423 |
5 |
3+N+PE |
6 |
|
|
|
||||
|
473503 |
480
- 500 |
3 |
2+PE |
7 |
|
473513 |
4 |
3+PE |
7 |
|
|
473523 |
5 |
3+N+PE |
7 |
|
|
|
||||
|
473463 |
440
- 460 |
4 |
3+PE |
11 |
|
473533 |
5 |
3+N+PE |
11 |
|
|
||||
 |
||
| CEE Straight
Male Plug with Cable Gland, IP 67 |
||
|
CEE 90° Male Plug
with Cable Gland, IP 67 |
||
|
CEE
Angled 82° Male Inlet, IP 67 |
||
  |
