Strain Relief Cord Connectors



SKINTOP®
Polyamide Style


Patented Security: Patent #: P-2631996
International Approvals:

UL # E146370
CSA # LR50370-10
VDE # 57986
SEV # 100989
  Protection: Up to 70 PSI
  Material: Polyamide - flame retardant, self-extinguishing nylon with neoprene bushing
  Rated Temperature: PG & NPT: -20°C to +80°C short term to +100°C
Metric: -20°C to +100°C

Seal:
IP 68 (International Protection - highest grade), comparable to NEMA 6 classification
First digit (0-6): Dust Protection
Second digit (0-8): Water Protection

Resistant to:
Salt water, weak acids, weak alcalis, alcohol, ester, ketones, ether, benzene, gas, mineral oil,animal and vegetable oils, gasoline, oil, grease, and common solvents*

SKINTOP® meets the most stringent demands of safety and operational reliability. SKINTOP® can be used in panels, switches, control boxes, submersible pumps, appliances and many machine tool applications.

SKINTOP ® is both a strain relief and a liquid tight seal - all in one connector.

Optimum Seal:
  Complete liquid tightness is achieved with a uniquely designed molded sealing ring and flange nut combined with a neoprene bushing and domed sealing cap.
Unique Design:
  SKINTOP® out performs traditional connectors because the design consists of three parts which do not require dismantling before use.

The internal ratchet mechanism allows the cap to be tightened without twisting the cord as it compresses, pushing the collet fingers together to form a liquid-tight seal with the neoprene
compression bushing.
Vibration Proof Protection:
  An integrated locking mechanism that includes an internal ratchet inside the sealing portion of the cord grip provides a self locking and vibration proof element that prevents the cap from loosening even when subjected to severe vibration.
Quick Installation:
  The multi-trapezoidal thread requires just one twist to tighten the dome cap – automatically adjusting to the size of the cable and providing optimum strain relief and liquid tight seal.
Durability:
  SKINTOP® incorporates a heavy duty design that provides greater pull out strength and very reliable strain relief.
Easier Handling:
  Larger ergonomic design and ridges in the dome cap provide easy gripping and mounting by hand or wrench.
Larger Variable Clamping Range:
  The uniquely designed collet, combined with the optional reducing bushing accommodates a broad range of cords, and cable diameters resulting in a reduction in the number of connectors required in inventory.
Resistant to Impact at Low Temperatures:
  The SKINTOP® can withstand impact at low temperatures of -20°C.
